Sand Blasting System

Get a Price/Quote

Product Details:

Usage & Applications Surface preparation, Rust removal, Paint stripping, Cleaning of metal surfaces
Production Capacity As per requirement
Automation Grade Semi-Automatic
Model No SBS-01
Installation Guideline Onsite support available
Frequency 50 Hz
Temperature Range Ambient
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Sand Blasting System Product Specifications

Color Blue / Grey
Voltage 380 V
Usage & Applications Surface preparation, Rust removal, Paint stripping, Cleaning of metal surfaces
Dimension (L*W*H) 1800 mm x 1100 mm x 2100 mm
Production Capacity As per requirement
Machine Type Pressure / Suction Type
Type Sand Blasting System
Automation Grade Semi-Automatic
Computerized No
Automatic Grade Semi-Automatic
Power 5 HP
Drive Type Electric
Weight (kg) Approx. 450 kg
Accessories Blasting nozzle, protective gloves, dust collector, air filters
Driven Type Electric
Power Consumption 3.75 kW
Control System Panel Based
Installation Guideline Onsite support available
Model No SBS-01
Capacity 100 kg / cycle
Temperature Range Ambient
Material Mild Steel
Frequency 50 Hz
Motor Power 5 HP
Features Sturdy construction, High durability, Corrosion resistant
Efficiency (%) 98%
Speed Adjustable
Surface Finish Matte / Uniform

Product Description

We have gained immense appreciation from clients for manufacturing and exporting premium quality Sand Blasting System. This system is widely used in construction, mineral, cement and many other allied industries. Offered to clients in different specifications in order to meet their specific requirements, this Sand Blasting System is reasonable in price. This system is stringently tested on various standard quality parameters before the final dispatch in market.

Features:

High operational fluency
Robust design
Anti- rust finish

Engineered for Reliability and Performance

SBS-01 offers unmatched durability and corrosion resistance, thanks to its robust mild steel construction and 5 mm chamber thickness. Sturdy blast hose and tempered glass viewing window ensure safe, continuous operation in demanding environments. The semi-automatic design combined with efficient controls makes it suitable for various surface finishing tasks.

Advanced Filtration and Safety Features

A cartridge-based dust collector maintains air quality while keeping noise levels below 75 dB. Integrated safety interlocks safeguard users, and accessories such as protective gloves and air filters are included. The system supports onsite installation, ensuring a seamless setup and safe operation throughout the production cycle.

FAQs of Sand Blasting System:

Q: How does the SBS-01 Sand Blasting System enhance surface preparation processes?

A: The SBS-01 utilizes high-efficiency abrasive blasting with aluminum oxide, glass beads, or steel grit to deliver uniform, matte surface finishes. Its optimized air flow and adjustable speed settings ensure thorough rust, paint, and residue removal, significantly improving surface cleanliness and adhesion for subsequent processes.

Q: What is the recommended air requirement for optimal blasting performance?

A: For efficient blasting, the system requires an air supply of 300-500 CFM at 7 bar. This ensures consistent abrasive flow, effective cleaning, and reduced cycle times, contributing to high productivity and superior surface results.

Q: When should the cartridge-based dust collector be serviced?

A: Typically, the cartridge dust collector should be inspected after every major blasting cycle or if a noticeable drop in extraction efficiency occurs. Regular maintenance extends filter life, preserves optimal air quality, and ensures safe operation.

Q: Where is onsite installation support available for this sand blasting system?

A: Onsite installation support is available across India through the manufacturers service network. Trained technicians assist with setup, calibration, and operational guidance to ensure the system is installed safely and tailored to site-specific requirements.

Q: What safety features are integrated in the SBS-01 sand blasting system?

A: The system includes safety interlocks, a tempered glass viewing window, and noise control mechanisms to keep levels under 75 dB. Protective accessories such as gloves and filtered air supply further enhance operator safety during use.

Q: How does the sand blasting process work in SBS-01 for different materials?

A: Abrasive media is propelled through a 19 mm ID blast hose using pressurized air, impacting surfaces to strip coatings, rust, or contaminants. Media type selectionaluminum oxide, glass beads, or steel gritcan be tailored based on surface material and desired finish quality.

Q: What benefits does using mild steel chamber construction provide?

A: Mild steels sturdy and corrosion-resistant properties ensure longevity and consistent performance under frequent, high-impact blasting conditions. This robust construction reduces maintenance needs and operating costs while maintaining reliable operation over time.
